In the last post we checked how to work with GCM on the client side.Now in this post we are going to post notification through PHP and MySql DB.
The Mysql DB will be used to store token ID generated from GCM..PHP will bind the Android and Mysql to send PHP notification to devices.
Part 1:Implementing push notification using GCM
lets get Started!
First we need to setup our Mysql DB to store token
Create a DB "gcmdb"
create database gcmdb;
Next we need to create table
Create table deviceinfo(tokenid varchar2(250) not null);
Next we need to create our php files, we are going to use PDOconnections
creating PDOConnections.php
<?php
$dbName = "gcmdb";
$user = "system";
$pwd = "1234";
$host = "localhost";
$cnn = new PDO('mysql:dbname='.$dbName.';host='.$host, $user, $pwd);
Fetching and Sending the request to GCM
Next we have to post request to server using gcm.php which will insert the token and retrieve it while sending notification.
prepare($query);
$stmt->bindParam(1, $token);
$stmt->execute();
echo("Insert success");
}
//Check exists token
function isExistToken($cnn, $token)
{
$query = "SELECT * FROM deviceinfo WHERE TOKENID = ?";
$stmt = $cnn->prepare($query);
$stmt->bindParam(1, $token);
$stmt->execute();
$rowcount = $stmt->rowCount();
return $rowcount;
}
?>
The Notification Page!Next creating the send notification page where we will send the notification messages to devices.
<?php
include("PDOConnection.php");
define('GOOGLE_API_KEY', 'AIzaSyCBV6kqW1sPsftrcnXeXqaJ8vZ2JbVQPyo');//Replace with your Key
$pushStatus = '0';;
if(isset($_POST['submit'])) {
$gcmRegIds = array();
$sql = "SELECT TOKENID FROM DEVICEINFO";
$result = $cnn->query($sql);
while($row = $result->fetch(PDO::FETCH_ASSOC))
{
array_push($gcmRegIds, $row["TOKENID"]);
}
$pushMessage = $_POST['message'];
if(isset($gcmRegIds) && isset($pushMessage)) {
$message = array('message' => $pushMessage);
$pushStatus = sendPushNotification($gcmRegIds, $message);
}
}
function sendPushNotification($registration_ids, $message) {
// Set POST variables
$url = 'https://android.googleapis.com/gcm/send';
$fields = array(
'registration_ids' => $registration_ids,
'data' => $message,
);
$headers = array(
'Authorization: key=' . GOOGLE_API_KEY,
'Content-Type: application/json'
);
// Open connection
$ch = curl_init();
// Set the url, number of POST vars, POST data
curl_setopt($ch, CURLOPT_URL, $url);
curl_setopt($ch, CURLOPT_POST, true);
curl_setopt($ch, CURLOPT_HTTPHEADER, $headers);
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
// Disabling SSL Certificate support temporarly
curl_setopt($ch, CURLOPT_SSL_VERIFYPEER, false);
curl_setopt($ch, CURLOPT_POSTFIELDS, json_encode($fields));
// Execute post
$result = curl_exec($ch);
if ($result === FALSE) {
die('Curl failed: ' . curl_error($ch));
}
// Close connection
curl_close($ch);
return $result;
}
?>
<html>
<head>
<title>GCM Server</title>
</head>
<body style="text-align:center;color:white">
<div style="background-color:#F2425A;height:100px;padding-top:15ppx;padding-bottom:15px;margin-top:-45px;width:100%">
<h1>AndroidXU</h1>
<h2 >Google Cloud Messaging (GCM) Server</h2>
</div>
<form method = 'POST' action = ''>
<div style="padding-top:10px">
<textarea rows = 6 name = "message" cols = 50 placeholder = 'Messages send to all device in database via GCM'></textarea>
</div>
<div style="margin-top:10px" >
<input type = 'submit' name="submit" value = 'Send Notification' style="background-color:#F2425A;color:#fff;padding:5px 5px 5px 5px;border:none">
</div>
<p>
<h3>
<?php
if('0' != $pushStatus)
{
$obj = json_decode($pushStatus);
if($obj != null)
{
echo("<div style='color:green'>");
echo("<p style='color:red'>Status:</p>");
echo("Success:".$obj->success);
echo("  Failure:".$obj->failure);
echo("</div>");
}
else
{
echo("<div style='color:red'>".$pushStatus."</div>");
} }
?>
</h3>
</p>
</form>
</body>
</html>
One you hit the URL: http://localhost/gcm/gcm.php. You can see the below page.
We need to send the request from our android code to PHP usng the token generated.
Finally Modifying the Java intent Service class
we are going to modify the GCMRegistrationIntentservice.java
if the token is already generated we will use shared preferances
if the token is already generated we will use shared preferances
package androidgreeve.android.com.gcmpushnotify;
import android.app.IntentService;
import android.content.Context;
import android.content.Intent;
import android.content.SharedPreferences;
import android.support.v4.content.LocalBroadcastManager;
import android.util.Log;
import com.google.android.gms.gcm.GoogleCloudMessaging;
import com.google.android.gms.iid.InstanceID;
import java.io.BufferedReader;
import java.io.IOException;
import java.io.InputStreamReader;
import java.io.OutputStream;
import java.net.HttpURLConnection;
import java.net.MalformedURLException;
import java.net.URL;
import java.util.HashMap;
import java.util.Iterator;
import java.util.Map;
/**
* Created by venkatesh on 15-05-2016.
*/
public class GCMRegistrationIntentService extends IntentService {
//Assigning success and failure Messages
public static final String REGISTRATION_SUCCESS = "RegistrationSuccess";
public static final String REGISTRATION_ERROR = "RegistrationError";
public static final String TAG = "GCMTOKEN";
public GCMRegistrationIntentService() {
super("");
}
@Override
protected void onHandleIntent(Intent intent) {
registerGCM();
}
private void registerGCM() {
SharedPreferences sharedPreferences = getSharedPreferences("GCM", Context.MODE_PRIVATE);//Define shared reference file name
SharedPreferences.Editor editor = sharedPreferences.edit();
Intent registrationComplete = null;
String token = null;
try {
InstanceID instanceID = InstanceID.getInstance(getApplicationContext());
token = instanceID.getToken(getString(R.string.gcm_defaultSenderId), GoogleCloudMessaging.INSTANCE_ID_SCOPE, null);
Log.w("GCMRegIntentService", "token:" + token);
//notify to UI that registration complete success
registrationComplete = new Intent(REGISTRATION_SUCCESS);
registrationComplete.putExtra("token", token);
String oldToken = sharedPreferences.getString(TAG, "");//Return "" when error or key not exists
//Only request to save token when token is new
if(!"".equals(token) && !oldToken.equals(token)) {
saveTokenToServer(token);
//Save new token to shared reference
editor.putString(TAG, token);
editor.commit();
} else {
Log.w("GCMRegistrationService", "Old token");
}
} catch (Exception e) {
Log.w("GCMRegIntentService", "Registration error");
registrationComplete = new Intent(REGISTRATION_ERROR);
}
//Send broadcast
LocalBroadcastManager.getInstance(this).sendBroadcast(registrationComplete);
}
private void saveTokenToServer(String token){
Map paramPost = new HashMap();
paramPost.put("action","add");
paramPost.put("tokenid", token);
try {
String msgResult = getStringResultFromService_POST("http://192.168.209.2/gcm/gcm.php", paramPost);
Log.w("ServiceResponseMsg", msgResult);
}catch (Exception e){
e.printStackTrace();
}
}
public String getStringResultFromService_POST(String serviceURL, Map<String, String> params) {
HttpURLConnection cnn = null;
String line = null;
URL url;
try{
url = new URL(serviceURL);
} catch (MalformedURLException e){
throw new IllegalArgumentException("URL invalid:"+serviceURL);
}
StringBuilder bodyBuilder = new StringBuilder();
Iterator<Map.Entry<String, String>> iterator = params.entrySet().iterator();
//Construct the post body using the parameter
while (iterator.hasNext()){
Map.Entry<String, String> param = iterator.next();
bodyBuilder.append(param.getKey()).append('=').append(param.getValue());
if(iterator.hasNext()){
bodyBuilder.append('&');
}
}
String body = bodyBuilder.toString(); //format same to arg1=val1&arg2=val2
Log.w("AccessService", "param:" + body);
byte[]bytes = body.getBytes();
try{
cnn = (HttpURLConnection)url.openConnection();
cnn.setDoOutput(true);
cnn.setUseCaches(false);
cnn.setFixedLengthStreamingMode(bytes.length);
cnn.setRequestMethod("POST");
cnn.setRequestProperty("Content-Type", "application/x-www-form-urlencoded;charset=UTF-8");
//Post the request
OutputStream outputStream = cnn.getOutputStream();
outputStream.write(bytes);
outputStream.close();
//Handle the response
int status = cnn.getResponseCode();
if(status!=200){
throw new IOException("Post fail with error code:" + status);
}
BufferedReader bufferedReader = new BufferedReader(new InputStreamReader(cnn.getInputStream()));
StringBuilder stringBuilder = new StringBuilder();
while ((line = bufferedReader.readLine())!=null){
stringBuilder.append(line+'\n');
}
return stringBuilder.toString();
}catch (Exception e){
e.printStackTrace();
return null;
}
}
}
check the logcat completely to identify flow,if you are facing difficulty try to uninstall app from device and run again.If you are facing any issue feel free to comment below.
Like,Share and suggest if you want it to be covered and happy Coding!
